2000W Digital High Frequency And Automotive Degas Ultrasonic Generator From 28khz/40khz

Message

$340.00

Have chosenThere are no options selected.

* Model Number
Start To Order

Add To Cart Successfully!

SEND INQUIRY
2000W Digital High Frequency And  Automotive Degas Ultrasonic Generator From 28khz/40khz

2000W Digital High Frequency And Automotive Degas Ultrasonic Generator From 28khz/40khz

  • Item No. 202011165af28
    MOQ 1 Set
  • Product size 45 x 42 x 26 cm
    Product weight 15 kg
Tag   wholesale

Available Options

Model Number
Add Request About This Product
Max file 5MB each
If lager file please send us email

Quantity:

From $ 340.00320.00310.00300.00  / Set
$ 340.00
You save  $  -340.00
Trade Assurance protects your orders
On-time Dispatch Guarantee
On-time dispatch is guaranteed or you will be eligible to claim platform compensation.
Refund Policy
If the shipment is delayed or product quality differs from what are specified in the online order, you can claim for a refund.
Quick refund: If you can apply for a refund within two hours of making a payment, you will receive a refund immediately.

If you have your own design, please contact us, there will have a professional customer service to communicate with you.

Don't have your files right now?No worries, Check out our art tips for more information.

If over 500pcs, mass production will start until pre-production sample has been approved.

Est. 7 days production

2000W Digital High Frequency And  Automotive Degas Ultrasonic Generator From 28khz/40khz



 1 (1).jpg

My company in 2012 launched a new generation of ultrasonic generator
1) a new generation of computer chip, dual display frequency current, more powerful
2) using a pulse width control, more accurate and more stable output power adjustment.
3) The automatic adjustment and automatic frequency tracking, so that the tone machine more stable easier
4) enhanced circuit protection functions: over-temperature protection and over current protection, so that more reliable
5) the new circuit structure optimization design, the whole rational layout and maintenance more convenient and less costly.



Standard configuration features:
1. Timer
2. Frequency display and adjusting
3. Current Display
3. Power adjusting
4. remote control connector /PLC connecting
5 .Output Power plug
6. High-frequency connector or CE connector (US ,EU or standard type)

Digital ultrasonic generator selectable frequency 17khz,20khz,25KHZ, 28KHZ,33khz, 40KHZ, 68KHZ, 80KHZ, 130KHZ,200khz or higher frequency, single-frequency ultrasonic generator.

Digital ultrasonic generator Power: 600W ~ 2400W, 2500W ~ 10000W (to be ordered) or a higher power.

It adopts international advanced figure pulse for driving; compared with traditional auto-excitation type control technology, it’s advantages like small in size, light in weight, powerful in power, stable and reliable in operation, continuous and adjustable in power and flexible in control have gained approval from many experts. Frequency scanning more ensured the machine can be at its best working state from the beginning to the end, which can express the potential of ultrasonic transducer to its maximum.



Feature:high cleaning efficiency, high cleaning speed, safe

Control system:PLC

Solvent:water-based cleaner , purity water, etc.

Function:Dirt Cleaning, Degreasing, Burnishing, Descaling, Stripping

Used Cleaning Process:Ultrasonic Cleaning -- Ultrasonic rinsing

Industry Used:electronic, optics,medical,photovoltaic,labware, lens



0-100% power adjustable linearly
Constant power output for different working conditions
Frequency tracking
Load self-adaption
Peak power technology which has better cleaning effect to stubborn stains
Frequency sweep function which can effectively eliminate stand wave and improve ultrasonic performance
Ultrasonic conversion efficiency higher
Industrial level LCD display supporting parameters setting and status monitoring
Internal protection for over current,over voltage and short circuit
Remote control,connectable to PLC





Type

Power(W)

Frequency (KHz)

Transducer numbers

Size

ARS-QXDY-2000W

2000W

17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

20-40

300x360x150



Multi-frequency Ultrasonic cleaning generator

Type

Power(W)

Frequency (KHz)

Size

AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE
AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE
All of machine are available for opening remote control function to connect with your own PLC system

ARS-SPDY-38/80 KHZ P 4

300W-1800W

38khz/80khz

300x360x150

ARS-SPDY-40/100KHZ P 4

300W-1800W

40khz/100khz

300x360x150

ARS-TPDY-28/83/130 KHZ P4

300W-1200W

28khz/83khz/130khz

300x360x150

ARS-TPDY-25/45/80KHZ P4

300W-1200W

25khz/45khz/80khz

300x360x150

ARS-TPDY-33/89/135KHZ P4

300W-1200W

33khz/89khz/135khz

300x360x150

ARS-TPDY-28/41/123KHZ P4

300W-1200W

28khz/41khz123khz

300x360x150

ARS-TPDY-40/80/120K

300W-1200W

40khz/80khz/120khz

300x360x150

ARS-FPDY-28/60/70/84KHZP4(quadruple frequency)60W70K

300W-1200W

28khz/60khz/70khz/84khz

300x360x150

ARS--FPDY-40/77/100/170KHZ P4

300W-1200W

40khz/77khz/100khz/170khz

300x360x150

Above ultrasonic generator 110V-120V or 220V-240V are available,contact with us during your order with detail request





2000w Digital High Frequency And  Automotive Ultrasonic Cleaning Machine Generator From 17khz to 40khz







.jpg






QQ20180710201055.jpgxj.jpgWhy choose us and About usCertification

8.jpg 9.JPG
