20KHZ-40KHZ Frequency Optional Ultrasonic Generator 300W-3000W For Ultrasonic Cleaning Equipment

My company in 2012 launched a new generation of ultrasonic generator
1) a new generation of computer chip, dual display frequency current, more powerful
2) using a pulse width control, more accurate and more stable output power adjustment.
3) The automatic adjustment and automatic frequency tracking, so that the tone machine more stable easier
4) enhanced circuit protection functions: over-temperature protection and over current protection, so that more reliable
5) the new circuit structure optimization design, the whole rational layout and maintenance more convenient and less costly.

Using the latest external excitation control circuit, the ultrasonic density is greatly improved, the cleaning work is more detailed, and the cleanliness is higher. The ultrasonic power generator has a frequency sweep function. During the cleaning process, the ultrasonic frequency is swept back and forth within a reasonable range to drive the cleaning liquid to form a fine backflow, so that the dirt on the workpiece is quickly removed from the surface of the workpiece while being ultrasonically peeled, improving the cleaning efficiency . Original imported high-power tube drive, up to 95% power factor, to ensure strong output power. It can also quickly remove dirt with strong adhesion. Under working condition, real-time frequency tracking is realized. Ensure that when the water temperature, the number of workpieces, and the cleaning agent change, when the frequency of the transducer changes, the generator can maintain the automatic frequency tracking at any time to achieve the best working condition that matches the frequency of the transducer.

Unique function: Real-time frequency tracking function under working condition. Ensure that when the water temperature, the number of workpieces, and the cleaning agent change, when the frequency of the transducer changes, the generator can maintain the automatic frequency tracking at any time to achieve the best working condition that matches the frequency of the transducer.
Tuning protection: During the tuning process, set a safe tuning current to ensure that tube burning is prevented during the tuning process.
Cleaning effect: The ultrasonic cleaning density is the highest in the domestic industry, the uniformity is the highest in the country, and the cleaning material is dead.

Standard configuration features:
1. Timer
2. Frequency display and adjusting
3. Current Display
3. Power adjusting
4.remote control connector /PLC connecting
5.OutputPower plug
6.High-frequency connector or CE connector (US ,EU or standard type)

Digital ultrasonic generator selectable frequency 17khz,20khz,25KHZ, 28KHZ,33khz, 40KHZ, 68KHZ, 80KHZ, 130KHZ,200khz or higher frequency, single-frequency ultrasonic generator.

Digital ultrasonic generator Power: 600W ~ 2400W, 2500W ~ 10000W (to be ordered) or a higher power.

It adopts international advanced figure pulse for driving; compared with traditional auto-excitation type control technology, it’s advantages like small in size, light in weight, powerful in power, stable and reliable in operation, continuous and adjustable in power and flexible in control have gained approval from many experts. Frequency scanning more ensured the machine can be at its best working state from the beginning to the end, which can express the potential of ultrasonic transducer to its maximum.

Ultrasonic generator can monitor the working frequency and power of high power ultrasonic system.
Can adjust various parameters in real time according to different requirements of users: power, amplitude, running time, etc.
Amplitude control: when the load changes during the working process of the transducer, the driving characteristics can be adjusted automatically to ensure the stable amplitude of the tool head.
