An ultrasonic generator is a conversion device that converts electrical energy into ultrasonic energy and provides energy to an ultrasonic transducer, also called an ultrasonic power source. The series of ultrasonic generators produced by our company are backed by domestic well-known experts and professors, and have absorbed advanced experience at home and abroad, and have been assembled and developed using imported high-power components.

Ultrasonic generators are widely used in ultrasonic cleaning, welding, drilling, polishing, homogenization, descaling and other fields. The products sell well all over the country and are well received by users.



The ultrasonic generator can monitor the working frequency and power of the high power ultrasonic system.
According to the different requirements of users, we can adjust various parameters in real-time, such as power, amplitude, running time and so on.
Frequency fine tuning: adjusting the frequency makes the ultrasonic transducer always work in the best condition, the efficiency reaches the maximum, and the adjustment range is 2%.
Automatic frequency following: once the device has completed its initial setup, it can operate continuously without the need to regulate the generator.
Amplitude control: when the transducer changes during the working process, it can automatically adjust the driving characteristics to ensure that the tool head has a stable amplitude.
System protection: when the system works in an unsuitable operating environment, the generator will stop working and display the alarm and protect the equipment from damage.
Amplitude adjustment: the amplitude can be increased or reduced instantly in the working process, and the setting range of amplitude is 0%~100%.
Automatic frequency search: it can automatically measure the working frequency of tool heads and store them.



Quality assurance:

1. Our machine is equipped with world advanced engine and components.Some parts of machine owned patents by ourselves. 2. Whole set of pure water processor line featured with RO anti-saturation and advanced testing devices 3. Manufactured in Seaport Shenzhen.

Type

Power(W)

Frequency (KHz)

Transducer numbers

Size

AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE
AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE
All of machine are available for opening remote control function to connect with your own PLC system

ARS-QXDY-300W

300W

17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

3-6

300x360x150

ARS-QXDY-600W

600W

17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

6-12

300x360x150

ARS-QXDY-900W

900W

17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

9-18

300x360x150

ARS-QXDY-1000W

1000W

17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

10-20

300x360x150

ARS-QXDY-1200W

1200W

17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

12-24

300x360x150

ARS-QXDY-1500W

1500W

17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

15-30

300x360x150

ARS-QXDY-1800W

1800W

17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

18-36

300x360x150

ARS-QXDY-2000W

2000W

17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

20-40

300x360x150

ARS-QXDY-2400W

2400W

17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

24-48

300x360x150

ARS-QXDY-3000W

3000W

17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

50-60

300x360x150

High Frequency

300W-1200W

54KHZ,60KHZ,68KHZ,70KHZ,80KHZ,100KHZ,120KHZ,135KHZ

High Frequency

100W-300W

175-200KHZ
