  • Item No.2021030596027
    MOQ1 Piece
  • Product size20 x 15 x 15 cm
    Product weight2 kg

Available Options

Model Number
Add Request About This Product
Max file 5MB each
If lager file please send us email

Quantity:

From $6.506.005.50 / Piece
$6.50
You save $ -6.50
Trade Assuranceprotects your orders
On-time Dispatch Guarantee
On-time dispatch is guaranteed or you will be eligible to claim platform compensation.
Refund Policy
If the shipment is delayed or product quality differs from what are specified in the online order, you can claim for a refund.
Quick refund: If you can apply for a refund within two hours of making a payment, you will receive a refund immediately.

If you have your own design, please contact us, there will have a professional customer service to communicate with you.

Don't have your files right now?No worries, Check out our art tips for more information.

If over 500pcs, mass production will start until pre-production sample has been approved.

Est. 7 days production

Quick Details
Frequency 40khz for Ultrasonic Cleaning Transducer
Length(mm) 57mm for Ultrasonic Cleaning Transducer
Place of Origin CN;GUA
Usage Vibration Sensor for Ultrasonic Cleaning Transducer
Brand Name OURS ULTRASONIC
customized Acceptable for Ultrasonic Cleaning Transducer
Piezoceramic PZT-4 Black for Ultrasonic Cleaning Transducer
Feature Long Life Low Cost for Ultrasonic Cleaning Transducer
Product name Ultrasonic Cleaning Transducer
Weight(g) 300g for Ultrasonic Cleaning Transducer
ConditionNew
After Warranty Service Video technical support
Local Service Location None
Showroom Location None
Material Stainless Steel for Ultrasonic Cleaning Transducer
Video outgoing-inspection Provided
Machinery Test Report Provided
Marketing Type Hot Product 2019
Applicable Industries Hotels
Power 50w for Ultrasonic Cleaning Transducer

Packaging & Delivery

Selling Units:
Piece
Single package size:
20 x 15 x 15 cm
Single gross weight:
2 kg

Hot Sales 50W 40KHZ Frequency Ultrasonic Transducer Price For Vegetable Washing


Ultrasonic vibrator, also called ultrasonic vibrating head, ultrasonic vibrating head, is a kind of ultrasonic transducer and the core component of ultrasonic cleaning machine. We call the whole of ultrasonic transducer and horn connected as vibrator. Ultrasonic transducer is one of the important components in the ultrasonic cleaning machine and ultrasonic vibration plate, which largely determines the quality of the ultrasonic effect.
Our company provides professional ultrasonic transducers with stable quality, high efficiency output and moderate price based on many years of ultrasonic cleaning experience, combined with the opinions and feedback of the majority of users.
Ultrasonic transducer is a device that converts high-frequency electric energy into mechanical vibration. The high-frequency electric energy input by the ultrasonic generator is matched with the piezoelectric ceramic sheet of the resonance frequency of the ultrasonic transducer. The electric energy is converted by the piezoelectric effect of the material Converted into mechanical vibration, that is, ultrasonic vibration, is transmitted to the water medium through the ultrasonic transducer, forming negative pressure bubbles and shock waves in the water, and transmitting them in the tax-based solution to achieve the effect of cleaning the surface stains of the workpiece. The transducer is mainly composed of aluminum block, piezoelectric ceramic sheet and insulating layer.


Ultrasonic transducer application:
1. Among all cleaning methods, ultrasonic cleaning is the most efficient and effective one. The reason why ultrasonic cleaning can achieve such an effect is closely related to its unique working principle and cleaning method.
2. We know that in production and life, there are many things that need to be cleaned, and there are many types and links that need to be cleaned, such as: removing pollutants from objects, dredging small holes, and common manual cleaning methods for special-shaped objects and hidden parts of objects. It is undoubtedly unable to meet the requirements. Even steam cleaning and high-pressure water jet cleaning cannot meet the higher cleanliness requirements. Ultrasonic cleaning can also kill bacteria, dissolve organic pollutants, and prevent over-corrosion. Therefore, ultrasonic cleaning Is increasingly widely used in all walks of life:
(1) Machinery industry: removal of anti-rust grease; cleaning of measuring tools; degreasing and derusting of mechanical parts; cleaning of engines, carburetors and auto parts; dredging and cleaning of filters and screens, etc.
(2) Surface treatment industry: degreasing and rust removal before electroplating; cleaning before ion plating; phosphating treatment; removing carbon deposits; removing oxide scale; removing polishing paste; surface activation treatment of metal workpieces, etc.
(3) Instrument and meter industry: high cleanliness of precision parts, cleaning before assembly, etc.
(4) Electronic industry: Removal of rosin and solder spots on printed circuit boards; cleaning of mechanical and electronic parts such as high voltage contacts.
(5) Medical industry: cleaning, disinfection, sterilization of medical equipment, cleaning of laboratory utensils, etc.
(6) Semiconductor industry: high cleanliness cleaning of semiconductor wafers.
(7) Clocks and watches, decoration industry: remove sludge, dust, oxide layer, polishing paste, etc.
(8) Chemical and biological industries: cleaning and descaling of laboratory utensils.
(9) Optical industry: degreasing, sweating and dust removal of optical devices.
(10) Textile printing and dyeing industry: cleaning textile spindles, spinnerets, etc.
(11) Petrochemical industry: cleaning and dredging of metal filter screens, cleaning of chemical containers, exchangers, etc.



Type

Length(mm)

Weight(g)

Frequency(KHz)

Resonance Impedance
(Ω)

Static Capacity
(pF)±10%

Input Power(W)

ARS-QXHNQ28100
PZT-4

66

624

28

10-20

6600

100

ARS-QXHNQ30100
PZT-8

61

555

30

10-20

5200

100

ARS-QXHNQ2560
PZT-4

77

530

25

10-20

5400

60

ARS-QXHNQ2860
PZT-8

68

470

28

10-20

3800

60

ARS-QXHNQ2850
PZT-4

82

425

28

10-20

4100

50

ARS-QXHNQ3360
PZT-8

58

420

33

10-20

3800

60

ARS-QXHNQ4060
PZT-8

55

300

40

10-20

3800

60

ARS-QXHNQ4060
PZT-4

56

310

40

10-20

5400

60

ARS-QXHNQ4050-1
PZT-4

57

300

40

10-20

4100

50
